Screed King power unit with GX-35 Honda 4-stroke engine
Product Code:
The Screed King is easy to use and saves time, service and manpower while providing the best finished concrete quality. The unique magnesium bar and power transfer system produces a high frequency vibration that eliminates the honeycomb effect and speeds finishing time.
Engine GX35 Mini 4-Stroke
Starting Mechanism Recoil
Maximum Power Output 1.5 HP @ 7000 RPM
Handle Design Vibration reducing, quick adjusting
Fuel Capacity 0.17 U.S. gallon (0.644 liter)
Oil Capacity 3.4 ounce U.S. liquid (0.1 liter)
Sound Pressure 87…90 dB(A) @ 5500 RPM
Vibration (m/sec2) 7.4 m/sec @ 5500 RPM in 4 in. (101.6 mm) slump concrete
Power Head Weight Single powerhead alone 27 lb (12.25 kg)
Dual powerhead alone 54 lb (24.25 kg)
Screed Bar Weight
4 ft (1.22 m) screed bar 8 lb (3.63 kg)
5 ft (1.52 m) screed bar 10 lb (4.54 kg)
6 ft (1.83 m) screed bar 12 lb (5.44 kg)
8 ft (2.44 m) screed bar 15 lb (6.80 kg)
10 ft (3.05 m) screed bar 19 lb (8.62 kg)
12 ft (3.66 m) screed bar 22 lb (9.98 kg)
14 ft (4.27 m) screed bar 26 lb (11.79 kg)
16 ft (4.88 m) screed bar 29 lb (13.15 kg)
16 ft (4.88 m) screed bar (double power unit) 31 lb (14.10 kg)
18 ft (5.49 m) screed bar (double power unit) 33 lb (14.97 kg)
20 ft (6.1 m) screed bar (double power unit) 37 lb (16.78 kg)
